Small-module precision gears: what to check first
Small-module precision gears can be sourced reliably only when the drawing, datum scheme, tooth specification and inspection method are agreed together. As the teeth become smaller, small variations in blank geometry, tool condition, heat-treatment distortion and measurement setup can consume a larger share of the functional tolerance. Ask for a drawing-based review rather than relying on a broad capability statement.
Control the features that become more sensitive at small module
- Define the gear, not just the module: confirm tooth count, pressure angle, helix hand where applicable, profile shift, face width and the functional mounting datums.
- Separate material route from final geometry: state the material, heat-treatment requirement and whether finishing stock or a post-heat-treatment operation is expected.
- Agree the inspection evidence: request the measured characteristics, datum reference and acceptance rule for profile, lead, pitch, runout and tooth thickness as applicable.
- Review the assembly context: mating part, center distance, backlash, torque, speed and noise target determine which tolerances are actually useful.
PairGears explains that accuracy grades need to be tied to the application and inspection data, not treated as a stand-alone label. See the gear accuracy grade guide before fixing an acceptance plan.
Example: turn a broad request into an inspectable requirement
For a compact actuator gear, an actionable RFQ would name the module and tooth geometry, attach the mating-part information, identify the bore or shaft datum, state material and heat treatment, and list the requested inspection records. PairGears can then review whether the requested tooth controls and manufacturing route fit the documented application; final feasibility should be confirmed against the approved drawing.
